Teledyne LeCroy Corporation Format of Traffic Generation Files
342 USB Protocol Suite User Manual
Bus Condition Keys
reset positive
integer
or
LS_EOP Host Generation Only.
Indicates the number of microseconds that
single‐ended zeros (SE0) are driven onto the
bus.
Assign a positive integer to this key.
This key can also be assigned the string LS_EOP
to drive two low‐speed bit times of SE0 followed
by one bit time of J.
se0 positive
integer
<2500 Host Generation Only.
Same SE0 signal as reset, but the range is in
nanoseconds (accuracy: +/‐ 33 ns).
suspend positive
integer Host Generation Only.
Indicates the number of microseconds of idle
and suspend after the previous packet (for
example, for ten milliseconds of suspend, the
key should equal 13000).
Assign a positive integer to this key.
Note that suspend begins after 3 milliseconds of
idle.
resume positive
integer Host Generation Only.
Indicates the number of microseconds of K
driven onto the bus.
Assign a positive integer to this key.
For a proper resume sequence, this should be
followed by the condition 
reset=LS_EOP speed=LOW.
wait_resume HERE Host Generation Only.
Place this immediately before a resume=<>
statement to implement a device resume, also
known as Remote Wakeup.
This causes the host to wait for the device to
issue the Resume (K) condition before the Host
proceeds with its own Resume signalling.
This statement MUST be followed by the 
resume=<> statement.
chirp HERE Used to create a chirp sequence for a High
Speed generation.
Usage: chirp=HERE
wait_vbus VALID Device Emulation Only.
Wait for VBus to go Hi.
Key Code Format Description
