USB Protocol Suite User Manual 331
Format of Traffic Generation Files Teledyne LeCroy Corporation
11.12.1 Script Control of Intelliframe vs Bitstream modes
To force the .utg file to run in IntelliFrame mode, add the following text string to the
FIRST LINE of the .utg file.
;intelliframe=ON
To force the .utg file to run in Bitstream mode, add the following text string to the
FIRST LINE of the .utg file.
;intelliframe=OFF
These commands are useful if an automated interface, such as the USB Compliance Suite,
is running a script.
If you run the script manually, to allow selection of IntelliFrame or Bitstream mode from
the toolbar, make sure the .utg file has no such Intelliframe command line.
TABLE 11.2: Support Keys for Defining Fields within a Packet
Key Code Format Description
File Control Keys
file_type UPAS
CHIEF This must be included at the beginning of the
file to determine the speed of packets to be
generated.
Value must be file_type=UPAS to allow for High
speed traffic, IntelliFrame operation,
expected_pid and device_pid key support.
Full and Low speed traffic, and Bitstream
operation are supported on all file_type=
values.
If this statement does not appear in the file, the
default is file_type=CHIEF, allowing backward
compatibility with older USB Chief™ .usb files.
file_version integer This must be included after the file_type= key
to determine the version of this file. Value is
currently 3.
Usage: file_version=3
file_mode HOST
DEVICE Sets generation mode to host or device.
For generation to work, this must match the
selection found in the Recording Options > Misc
dialog.
