9.8.2 Link Tracker Buttons
The Link Tracker window has a row of buttons for changing the format of the displayed
data and for exporting data: The buttons have the following functions:
Full Screen. Expands the Link Tracker window to fill the entire
screen.
Synchronize with Other Views. Synchronizes Views so that a move
in one window repositions the other.
Because of the differences in scale and logic between the Link
Tracker and Trace view window, scrolling produces different effects
depending on which window is being scrolled.
Scrolling in the trace window causes the Link Tracker window to
rapidly jump from event to event. Long periods of idle time are
thus skipped.
Scrolling in the Link Tracker window, in contrast, produces modest
movements within the trace window.
Scrolling in the Link Tracker window causes the trace window to
pause until the beginning of a packet is displayed. At that point, the
trace window repositions itself. While scrolling long Idle periods or
through the contents of a packet, the trace window does not move.
View Options. Opens a menu with three options:
Collapsible Idle Time (Collapse Idle Bigger Than n nanoseconds. 
Note: Does not affect Collapse Idle Plus.)
Time Format (Seconds, Clock)
Reset Columns Widths (return to default widths)
Reset Columns Order (return to default column sequence)
See
“Using the Link Tracker Window” on page 232 for further
details.
Zoom In
Zoom Out
Continuous Time Scale. No collapsing.
Collapse Idle. Do not show some periods of Link being idle.
Collapse Idle Data. Do not show periods of Link being idle.
Show Descrambled Bytes
