The Main Display Window
Teledyne LeCroy Corporation
Zoom In
Increases the size of the displayed elements.
Zoom Out
Decreases the size of the displayed elements.
Wrap
Wraps displayed packets within the window.
Synchronize Trace
View with Other
Views
Synchronizes the Trace view with other views
Show USB 2 Traffic
Only
Displays only USB 2.0 traffic.
Show USB 3 Traffic
Only
Displays only USB 3.0 traffic.
Hiding USB 2
Traffic
Hides.
SOF’s: Start of Frames
Chirps: Chirp‐K and Chirp‐J Bus conditions (these are recorded only)
Hiding USB 3
Traffic
Hides:
Hide All Except Transfers
Hide Upstream Transfers
Hide Downstream Packets
Training Sequence Packets ‐ TSEQ, TS1/TS2
Hide Link Commands ‐ LUP/LDN, Flow Control, Power Management
Bus Event ‐ Hide LFPS Packets, Hide Electrical Idles, Hide
Terminations
Miscellaneous ‐ Hide LMP Packets, Hide ISO Time Stamp Packets,
Hide Inter‐Packet Symbols, Hide Skip Sequences,
Hide Logical Idle Packets, Hide Loopback Packets
(BCNT, BRST, BERC), Hide Compliance Packets
Hide LTSSM Transition Indicators
Hide Devices
(Addr/Endp....
Opens the Hiding Devices dialog displaying packets belonging to
specified devices by address and endpoint
NAKs/NRDYs
Shows/Hides NAK’d and NRDY’d Transactions
View Layers Mode Display All Layers, Application Layers, or Lower USB Layers.
Stacking View
Puts a group of packets in one row, to shorten display. See
.
Apply Decoding
Scripts
Decoding scripts set the values of the display and recording options
for optimum views of trace information from specific vendors or
classes of data. This menu option allows you to select the vendor or
class of data for the request recipients and endpoints listed in the
Request Recipients and Endpoints menu. You can keep the settings
across recordings.
See
.
Packet Level
Displays Packets.
Transaction Level
Displays Transactions.
Menus
Functions
