USB Protocol Suite User Manual 27
Advisor T3 Teledyne LeCroy Corporation
The system provides on‐the‐fly detection of, and triggering on, such events as Tokens and
Errors. Whether recording manually or with a specified trigger condition, the system
continuously records the link data, in a wrap‐around fashion, until manually stopped or
until the system detects the Trigger Event and records the specified post‐trigger amount
of link data.
Upon detection of a triggering event, the Analyzer continues to record data up to a point
specified by you. You can individually enable or disable real‐time event detection to allow
triggering on events as they happen, including predefined exception or error conditions
and user‐defined sets of trigger events. An externally supplied signal can trigger the
Analyzer.
You can use search functions to investigate particular events. In addition to immediate
analysis, you can print any part of the data. You can save the data on disk for later
viewing. You can generate timing information and data analysis reports.
Please refer to the Universal Serial Bus Specification for details on the protocol. The USB
specification is available from the USB Implementers Forum (USB‐IF) at:
1.3.2 Features
General
 Fully complies with USB specification revisions.
 Has field‐upgradeable firmware.
 Supports all USB speeds (5 GB/s, 480 MB/s, 12 MB/s, and 1.5 MB/s).
 Displays bus traffic using color and graphics in the CATC Trace interface.
 Has free non‐recording, view‐only Trace Viewer software.
 Comes with online manual.
 Self‐diagnoses at power on.
 Allows remote control of USB analyzers in a network.
Flexible 3.0 Calibration
Each link can be calibrated with respect to received equalization and gain.
Physical Components
 Desktop or portable Microsoft Windows XP, Windows 8, or Windows 7 (32 or 64)
host machine with USB capability
 Plug‐and‐Play USB installation
 2 GB of physical data‐recording memory
 USB 2.0 Hi‐Speed connection to desktop or portable host machine
 DC power supply
 Expansion port for optional External Trigger In/Out cable, as well as multi‐box
synchronized recording
 USB 3.0 connectors for SuperSpeed capture and generation
USB Implementers Forum
1730 SW Skyline Blvd. 
Suite 203
Portland, OR 97221 Tel: +1/503.296.9892
Fax: +1/503.297.1090
Web: http://www.usb.org/
