Teledyne LeCroy Corporation Format of Traffic Generation Files
346 USB Protocol Suite User Manual
raw_data_bits
Not supported for
Hi Speed Traffic on
Voyager M3x. integer Use to send a non‐modulo 8 number of bits in a
classic speed raw_data packet.
It is only valid in conjunction with the raw_data
statement.
Normally, every bit of the array defined in a
raw_data=(xx yy) type of statement would be
sent. However, particularly in the case where
bit_stuff=off, you need more control over the
number of bits to be output on the bus. By
adding the statement raw_data_bits = 11, only
the first 11 bits of the defined bytes are sent.
For the following case,
raw_data=(8F F0) raw_data_bits=13
the output bitstream would be:
1111 0001 0000 1
(Each byte is described in MSB to LSB format,
but is output on the wire in LSB to MSB format.)
bit_stuff
Not supported for
Hi Speed Traffic on
Voyager M3x. OFF
ON Assign the string OFF to disable bit stuffing
within the current packet.
The default value is ON.
sync integer
1‐40 Assign an integer from 1 to 40 to represent the
sync field. The integer is the number of zeros
transmitted before the one.
For Low and Full Speed files, the default value is
7 to give a sync of 00000001.
For High Speed files, the default value is 31
resulting in a sync of
00000000000000000000000000000001.
retry
ping_on_retry
ping_on_nak
retry_next_frame TRUE
FALSE Host Generation Only.
These four keys may be applied to individual
packets to override the behavior in a given
instance.
Normally, they are used in the config_endpoint
statement.
See their descriptions in the Endpoint
Configuration section earlier.
Keys for Class Decoding
These keys are populated into the .utg. script file automatically whenever the menu
command File > Export to .utg file is run. These keys do not need to be edited.
sd_prod
Key Code Format Description
