Setting Up the Analyzer ‐ Ethernet Connection

USB Protocol Suite User Manual

2. Connect the USB port to a USB port on the host machine using the LONG (6‐foot/2‐

meter) USB 2.0 cable.

3. Insert the Installation CD.
4. Turn on the power switch.

Note:

At power‐on, the Analyzer initializes itself in approximately ten seconds and performs an

exhaustive self‐diagnostic that lasts about five seconds. If the diagnostics fail, call Teledyne
LeCroy Customer Support for assistance.

5. Click Next after you see the Add New Hardware Wizard window.

6. Follow the Microsoft

Windows

on‐screen Plug‐and‐Play instructions for the

automatic installation of the Analyzer as a USB device on your analyzing host
machine (the required USB files are included on the Installation CD).

7. Click Finish when you see the message that says Windows has finished installing

the software that your new hardware requires and the driver files have been
installed in your host machine.

8. Check Analyzer setup in the “Application Startup” section (See

WARNING:

Do not change from USB to Ethernet, or back, without power cycling the Analyzer.

Note:

Disconnection of USB or Ethernet during capture or uploading of trace data is not supported,

and may cause the software to malfunction or crash.

3.3

Setting Up the Analyzer - Ethernet Connection

To set up an Analyzer using an Ethernet connection:

1. Connect the provided AC power cord to the rear of the Voyager M3/M3i and to a

100‐volt to 240‐volt, 50‐Hz to 60‐Hz, 100‐W power outlet.

Note:

The Analyzer is capable of supporting supply voltages between 100 volts and 240 volts, 50 Hz or

60 Hz, thus supporting all supply voltages around the world.

2. Insert the Installation CD.
3. To use a DHCP network, make sure that the host machine connects to a DHCP

network, then connect the Ethernet port on the Analyzer to the DHCP network.

Note:

If the DHCP network uses a Firewall, you must set the Firewall to allow the Analyzer device on

the network.

Note:

Direct connection from the Ethernet port on the host machine to the Ethernet port on the

Analyzer is supported in this release. See

4. Turn on the power switch.
