Page 228
Teledyne LeCroy Corporation
Bus Utilization
228
USB Protocol Suite User Manual
9.7.3
Graph Areas Menu
The Graph Areas menu allows you to view different information in the Bus Utilization
window. To view information:
1. Click the
button to open the Graph Areas menu. For USB 2.0. the display is
similar to the following:
Figure 9.20: Graph Areas Menu USB 2.0
