Teledyne LeCroy Corporation Tool Bar
84 USB Protocol Suite User Manual
4.3.2 Zoom and Wrap
4.3.3 Miscellaneous
4.3.4 Analysis (Reports)
Zoom In Zoom Out
Wrap
Display Realtime Statistics.
See
“Real Time Monitoring”
on page 253 .
Assign High Level Decodes.
See
“Decode Requests” on
page 185 .
Display Stacking View. See “Stacking” on page 127 .
Trace Information Report
See
“Trace Information” on
page 210 .
Error Report
See
“Error Summary” on
page 214 .
Timing and Bus Usage
Calculations
See
“Timing Calculations” on
page 218 .
Traffic Summary Report
See
“Traffic Summary Report”
on page 222 .
Data View
See
“Data View” on page 221 .
Bus Utilization
See
“Bus Utilization” on
page 224 .
Link Tracker
See
“Link Tracker (3.0)” on
page 231 .
Spec View
See
“Spec View (3.0)” on
page 243 .
Open the Navigator bar
See
“Using the Navigator” on
page 235 .
Detail View
See
“Detail View” on
page 242 .
Decoded Fields View.
See “Decoded Fields View” on
page 204 .
Show USB 3.0 LTSSM View
See
“USB 3.0 LTSSM View” on
page 246 .
