USB Protocol Suite User Manual 35
Voyager M3x Analyzer Teledyne LeCroy Corporation
You can use search functions to investigate particular events. In addition to immediate
analysis, you can print any part of the data. You can save the data on disk for later
viewing. You can generate timing information and data analysis reports.
Please refer to the Universal Serial Bus Specification for details on the protocol. The USB
specification is available from the USB Implementers Forum (USB‐IF) at:
1.5.3 Features
General
 Fully complies with USB specification revisions.
 Supports the Link Power Management extension.
 Uses field‐upgradeable firmware and recording engine.
 Supports all USB speeds (5 Gb/s, 480 Mb/s, 12 Mb/s, and 1.5 Mb/s).
 Displays bus traffic using color and graphics in the user‐friendly CATC Trace inter‐
face.
 Has free non‐recording, view‐only Trace Viewer software.
 Comes with online manual.
 Self‐diagnoses at power on.
 Uses software upgradable Exerciser function.
 Allows remote control of USB analyzers in a network.
Flexible 3.0 Calibration
Each link can be calibrated with respect to received equalization and gain.
Physical Components
 Desktop or portable Microsoft Windows XP, Windows 8, or Windows 7 (32 or 64)
host machine with USB or Ethernet capability
 Plug‐and‐Play USB installation
 4 GB of physical data‐recording memory
 USB 3.0 Super‐Speed connection to desktop or portable host machine
 USB 3.0 connectors for SuperSpeed capture and generation
 Integrated CATC Sync ports to support cascading analyzers or Cross‐Sync configu‐
rations
Recording Options
 Versatile triggering: bit‐wise value and mask data patterns up to sixteen bytes
wide for Setup transactions and data packets
 Triggering on High‐Speed PIDs and split transaction special tokens (ERR, SPLIT,
PING, NYET, DATA2, and MDATA) (2.0)
 CATC Trace display and enumeration of High‐Speed Micro Frames (2.0)
 Three forms of triggering: Snapshot, Manual, and Event
 Transaction sequencer: Allows triggering on a token qualified by a data pattern
USB Implementers Forum
1730 SW Skyline Blvd. 
Suite 203
Portland, OR 97221 Tel: +1/503.296.9892
Fax: +1/503.297.1090
Web: http://www.usb.org/
