Teledyne LeCroy Corporation Hide SOF Packets (2.0)
130 USB Protocol Suite User Manual
This also hides 3.0 NRDY transactions, if they are virtual equivalents of a 2.0 NAK
situation.
5.17 Hide SOF Packets (2.0)
You can hide Start‐of‐Frame (SOF) packets that may be uninteresting in a given context
from a Trace View by clicking the Hide SOF Packets button on the Tool Bar:
 Click the button to show/hide all SOF packets.
Note: This also hides low‐speed EOPs.
5.18 Hide Chirps (2.0)
Click the button to hide any Chirped‐J or Chirped‐K packets recorded in a USB 2.0 Hi‐
Speed trace.
5.19 Hide Upstream Packets (3.0)
Click the button to Hide Upstream Packets.
5.20 Hide Downstream Packets (3.0)
Click the button to Hide Downstream Packets.
5.21 Hide Link Training Sequences (3.0)
Click the button to Hide Link Training Sequences and select from the options
to show/hide TSEQ TS1/TS2.
5.22 Hide Link Commands (Flow Control) (3.0)
Click the button and select from the options to show/hide Link
Commands (LUP/LDN, Flow Control or Power Management).
