USB Protocol Suite User Manual 193
Class/Vendor Decoding Options Teledyne LeCroy Corporation
 NCM Class Requests
 Personal Healthcare Requests
 Printer Class Requests
 RNDIS Requests
 RNDIS Requests ‐ microsoft
 Standard Requests
 Still Image/PTP/MTP/PictBridge Class Requests
 USB Test and Measurement
 USB3 Vision Requests
 Video 1.0 Class Requests
 Video 1.1 Class Requests
 Video 1.5 Class Requests
 WA Radio Control Request
 WMC Class Requests
 WUSB CBAF Requests
5. Select a decoding group.
OR
Select No Decoding if you do not want any specific decoding.
6. Repeat the previous steps for additional recipients.
7. To retain a mapping from trace to trace DURING an application session, select the
Keep Across Recordings checkbox.
8. Click OK.
8.2.2 Mapping Endpoint to Class/Vendor Decoding
To assign a Class/Vendor Endpoint decoding,
1. Click the Apply Decoding Scripts on the Toolbar or press Ctrl+Shift+Y
OR
Right‐click the Bulk/Int Transfer field to display the USB Device Request menu.
2. Select Map Endpoint to Class/Vendor Decoding to display the Request Recipients
and Endpoints dialog box.
3. Click the Endpoints tab to display the Endpoints dialog box.
