352 USB Protocol Suite User Manual
Header TP or ACK TP.
 Upon RX of Data burst packets: Exerciser automatically sends ACK TP with
proper SEQ number for all received packets.
 Upon RX of DP with out of order SEQ number: Exerciser sends ACK TP with
missing SEQ number and Retry bit set to 1.
 Upon RX of DP with Host Error bit set: Exerciser (in Device Emulation mode)
automatically waits for ERDY and then retries packet.
 Upon RX of Stream Transfer with out‐of‐order data packets: Exerciser sends
ACK TP with correct Stream ID and SEQ number.
Note: For more information on the theory of operation of the Transaction Engine and the use of the
Scripting language, consult the Voyager USB 3.0 Exerciser Generation Script Language Reference
Manual.
12.5 Exerciser Files
The system generates USB 3.0 traffic from traffic generation files (*.usb3g) which are
text‐based script files that instruct the Exerciser how to generate USB 3.0 traffic. These
script files can be edited with either a simple text editor such as Notepad or with the
Script Editor utility provided by the application.
12.6 Creating Exerciser Files
If you choose to write a script with a text editor, a good way to start is to edit a sample
generation file.
For Windows 7 and Windows 8, an example such as: MassStorageEnumeration.USB3g,
SampleEnumHostTx.usb3g, or SampleMassStorageHostTx.usb3g, in the directory
C:\Users\Public\Documents\LeCroy\USB Protocol Suite\Examples\3.0 Host
Emulation\LowLevelScripts.
For Windows XP, an example such as: MassStorageEnumeration.USB3g,
SampleEnumHostTx.usb3g, or SampleMassStorageHostTx.usb3g, in the directory
C:\Program Files\LeCroy\USB Protocol Suite\Examples\3.0 Host
Emulation\LowLevelScript
s.
You can open a generation file with Notepad or other editor and then add or remove text
as needed.
For complete information on these and other Exerciser commands, see the Exerciser User
Manual (VoyagerUSB3ExerciserScriptLanguage.pdf) included in your installation
Documents folder.
12.7 Exerciser Window
Click the USB 3.0 Exerciser button to open the
USB 3.0 Protocol Exerciser window.
