The Main Display Window
78
USB Protocol Suite User Manual
Search
(see
“Searching Traces” on page 149
Go to Trigger
Positions the display to show the first packet that follows the trigger
event.
Go to Selected
packet
Positions the display to show the selected packet .
Go to Packet/
Transaction/
Transfer
Positions the display to the packet/transaction/transfer number
selected in the Go to Packet/Transaction/Transfer menu.
Go to Marker »
Positions the display to the selected marked packet.
Go to USB 2.0»
Positions the display to the selected event, condition, value, or type.
Go to USB 3.0»
Positions the display to the selected event, condition, value, or type.
Go to Channel
Positions the display at selected channel. Select from 0,1,2 and 3.
Go to SCSI
Positions the display to the selected SCSI Operation,
Command Status, Task Management, Task Management Response,
Error or SCSI Logical Unit Number
.
Find
Allows complex searches on multiple criteria.
See
.
Find Next
Repeats the previous Find operation.
Search Direction
Allows the search direction to be changed from Forward to
Backward, or vice versa.
View
Toolbars
Displays list of available toolbars.
See
“Resetting the Toolbar” on page 92
.
Analyzer Network
Chat Bar
Opens a dialog that allows you to conduct chat sessions over an IP
LAN. In order to send and receive electronic text messages, each user
must be working with a host machine that is on an IP LAN and also
attached to an analyzer.
Status Bar
Switches display of the Status Bar on or off.
See
.
QuickTiming Bar
Quick Timing provides immediate time deltas and bandwidth
calculations. If the Start is placed on a packet that contains an
Address and Endpoint, the bandwidth for that combination is
displayed in the Status Bar below the trace data.
CATC Walk
Select Play to start playing the CATC Walk playlist or Manage Playlists
to display the Edit CATC Walk Playlists dialog to manage playlists.
Real‐time Statistics Allows you to view traffic statistics as they occur.
“Real Time Monitoring” on page 253
.
USB Electrical Test Tests electrical characteristics.
“USB 3.0 Electrical Test Modes” on page 373
Trace Views
Displays CATC Trace, Compressed CATC Trace, Spreadsheet (Color), or
Spreadsheet (B/W).
Unhide cells
Unhide previously hidden Traffic, VBus Power, or Unhide All.
Menus
Functions
