Teledyne LeCroy Corporation Script Editor
356 USB Protocol Suite User Manual
12.8.1 Highlighting
 All known commands and parameters are highlighted in blue.
 All predefined values and command modifiers are highlighted in brown.
 Comments are in green.
 Errors are in red.
12.8.2 Text Editing Commands
The Script Editor supports standard editor commands using toolbar buttons and Edit
menu commands:
 Undo/Redo
 Cut/Copy/Paste: Also available by right‐clicking a command to display a menu
 Bookmarks: Toggle, Previous/Next, and Clear All
 Find/Replace/Find Next/Go to
12.8.3 Help
Right‐click a command to display a menu from which you can choose Help.
12.8.4 Properties Window
The Properties window lists all parameters and their values for the selected script
command. Parameters/values can be changed by entering text into the text boxes or by
selecting items from pull‐down menus.
12.8.5 File Tabs
At the top of the Script Editor window is a tab with the name of the open generation file.
If there are Include statements in the generation file that link it to other generation files,
these files automatically open and display as tabs at the top of the window. You can click
the tabs to toggle between the open generation files.
12.8.6 Errors
When you compile a script and have an error, the error appears in the Error tab at the
bottom of the application window. Each error has a file name, line number, and
description. Double‐clicking the error jumps to the line number.
A red square appears next to the line number that contains the error.
A yellow square appears next to the line number that has a warnings.
Note: You cannot run a script that has syntax errors.
