Teledyne LeCroy Corporation

Recording Option Summary Tab

314





USB Protocol Suite User Manual

10.12 Recording Option Summary Tab

Click the vertical triple greater‐than symbols on the right to display the
Recording Options Summary tab:

Figure 10.32: Recording Options - Summary Tab

The Summary tab provides an easy‐to‐read summary of the currently selected options.
