Teledyne LeCroy Corporation Markers
108 USB Protocol Suite User Manual
As shown above you can:
5.2.3 Attaching Markers
You can attach a discrete piece of information/data to a marker, for example, a text
description or file, an attachment of a trace file by a predefined order, video or audio
files, URL links or any other files. You can also remove an attachment from a Marker.
5.2.4 Adding an Attachment
Perform the following steps to add an attachment to a marker:
1. Right‐click on any cell in the trace and select Set Marker.
The Create Marker window displays.
2. Click on the Add icon.
The Add File to the Marker dialog displays.
3. Go to the file and select it to add it to the marker as an attachment.
4. Click Open.
The file will appear in the Create Marker for Transfer... dialog (see Figure 5.8 on
page 109 ). The Marker # appears in the top panel, the icons are displayed in the
second panel and you can click on the icon on the third panel to view the file you are
about to attach.
5. Click OK to add the attachments.
Add icon. Click on this
icon to add any file. See
“Adding an Attachment”
on page 108.
Export icon. Click on this icon to
export an attachment.
Record icon. Click on this
icon to record audio. See
“Recording an Audio
File” on page 109.
Delete icon. Click on this icon to
delete an attachment
New URL icon. Click on
this icon to add any URL.
