87
E ES4710BD 10 Slots L2/L3/L4 Chassis Switch
4.2.1.1.2 Admin Mode
Admin Mode prompt “Switch#” can be entered under the User Mode by running the enable
command and entering the corresponding admin user password, if set. Or, when the exit command is
run under Global Mode, it will return to the Admin Mode. ES4710BD also provides the shortcut key
sequence "Ctrl+z”, that allows an easy way to exit to Admin Mode from any configuration mode
(except User Mode).
Under Admin Mode, the user can query the switch configuration information, connection status
and traffic statistics of all ports; and the user can further enter the Global Mode from Admin Mode
to modify all configurations of the switch. For this reason, a password must be set for entering
Admin mode to prevent unauthorized access and malicious modification to the switch.
4.2.1.1.3 Global Mode
Type the config command under Admin Mode to enter the Global Mode, and prompt
“Switch(Config)#” will appear. Use the exit command under other configuration modes such as
Interface Mode or VLAN mode to return to Global Mode.
The user can perform global configuration settings under Global Mode, such as MAC Table,
Port Mirroring, VLAN creation, IGMP Snooping start, GVRP and STP, etc. The user can also go
further to Interface Mode for configuration of all the interfaces
4.2.1.1.3.1 Interface Mode
Use the interface command in Global Mode to enter the interface mode specified. ES4710BD
provide three interface type (VLAN interface, Ethernet port, port-channel) and accordingly, the
three interface configuration modes. Information is as follows:
Interface Type Entry Prompt Operates Exit
VLAN
Interface
Type interface vlan
command under
Global Mode.
Switch(Config-If-V
lanX)#
Configures
switch IPs, etc
Use the exit
command to
return to
Global Mode.
Ethernet Port Type interface
ethernet
command under
Global Mode.
Switch(Config-
ethernetxx)#
Configures
duplex mode,
speed, etc. of
Ethernet Port.
Use the exit
command to
return to
Global Mode.
port-channel Type interface
port-channel
ber> command
Switch(Config-if-
port-channelx)#
Configures
port-channel
related settings
such as duplex
Use the exit
command to
return to
Global Mode.
