68
E ES4710BD 10 Slots L2/L3/L4 Chassis Switch
Step 4: Tighten (clockwise) the panel fasteners in the front of XENPAK transceiver until fastened
to the front panel of the 10GB line card.
Note: the XENPAK 10GB fiber transceiver is hot swappable
Do not stare directly at the 2 fiber bore in the XENPAK 10GB fiber transceiver when the switch is
in operation. The laser may hurt your eyes.
2.3.8 Copper Cable/Fiber Cable Connection
Ethernet cable connection:
Step 1: Insert one end of the Ethernet cable into the RJ-45 Ethernet port in the switch copper
cable line card
Step 2: Insert the other end of the Ethernet cable into the RJ-45 Ethernet port of the other device
Step 3: Check all status indicators for the corresponding ports, a lighted LINK indicates the link
has been established, otherwise the link is not ready and the cable should be examined
Upon connection, please verify the sign above the port to avoid use of other ports, which might
damage to the modules or the switch.
The connection procedure for fibers are listed below:
Step 1: Remove the protective dust plug from the SFP/XENPAK fiber transceiver bore; take out
the fiber cable and remove the protective cap from one end of the fiber cable. Keep the
fiber end clean and neat.
Step 2: Immediately attach the end of the fiber cable to the SFP/XENPAK transceiver, and the
other end to the transceiver of the corresponding device. Note: Upon connection, the
SFP/XENPAK transceiver’s TX port should be connected to the RX port of the
corresponding device, and vice versa.
Step 3: Check the fiber port status indicator, a lighted LINK indicates that the link has been
established, otherwise the link is not ready and should be examined.
Upon connection, please verify the sign above the port to avoid using other ports, which might
damage the transceiver or the other ports.
When connecting the other device through fiber cable to the switch, the output power of the fiber
must not exceed the maximum received power of the corresponding modules, otherwise, it will
damage the switch. Do not stare at the fiber bore when the switch is in operation to avoid harm.
2.3.9 Power supply connection
Connection procedures for the AC power supply module are described below:
Notice
Notice
Notice
