E ES4710BD 10 Slots L2/L3/L4 Chassis Switch
2.3.5 Connecting to the Management Port
The EM4710BD-AGENT provides a RJ-45 (female) Ethernet port. Users can connect to this
administration port through a backend host with Ethernet interface for program loading, or use this
port to connect to remote devices (e.g., an administrative workstation) for remote administration.
The connection procedure is listed below:
z
Connecting to a back-end PC
Step 1: Find a PC with Ethernet Interface
Step 2: Connect the PC to the RJ-45 Ethernet port of the switch with a twisted-pair crossover
cable
z Remote Administration of the device
Step 1: Connect the administrative Ethernet port in the main controlling board to a Hub with
a standard network cable
Step 2: Connect the Hub to an administrative workstation in the local area network.
Or,
Step 1: Connect the administrative Ethernet port in the main controlling board to a router
with a crossover network cable
Step 2: Connect the router to an administrative workstation in the wide area network.
2.3.6 SFP transceiver installation
In the ES4710BD, each line card with a 1000BASE fiber interface provides several SFP 1000BASE
transceiver slots.
The procedure for installing the SFP 1000BASE fiber transceiver is shown below:
Step 1: Put on a ESD wrist strap (or antistatic gloves)
Step 2: Insert the SFP transceiver onto the guide rail inside the 1000BASE fiber interface line card
Do not put the SFP transceiver up-side-down.
Step 3: Push the SFP transceiver along the guide rail gently until you feel the transceiver snap into
place at the bottom of the line card.
Note: the SFP 1000BASE fiber transceiver is hot swappable.
Do not stare directly at the 2 fiber bore in the SFP 1000Base fiber transceiver when the switch is in
operation. The laser may hurt your eyes.
2.3.7 XENPAK transceiver installation
In the ES4710BD, Each EM4700BD-2XG-XENPAKline card provides 2 XENPAK 10GB fiber
transceiver slots. The procedure for installing the XENPAK 10GB fiber transceiver is shown below:
Step 1: Put on an ESD wrist strap (or antistatic gloves)
Step 2: Insert the XENPAK transceiver onto the guide rail inside the 10GB line card. Do not put
the XENPAK transceiver up-side-down.
Step 3: Push the XENPAK transceiver along the guide rail gently until it comes into contact with
the front panel of the 10GB line card.
Notice
