296
E ES4710BD 10 Slots L2/L3/L4 Chassis Switch
Apply to add the group.
After finishing the group configuration, the configured port information will be shown under the
configuration table.
13.5.2 LACP port configuration
Click LACP port configuration to enter configuration page
Equivalent to CLI command 13.2.2.2
z
group num
z Port: will be added or deleted
z Port mode: active, passive or on
z Operation type: add port to group or remove port from group
Fill up group num, select Port and Port mode, operation type as add or to group. Click Apply button
to add port into the group.
Display port member
Select a group num in port configuration and the information of port member will be shown under
the configuration table. Equivalent to CLI command 13.4.1.1.
z
Port: name of port member
z Port mode: active or passive
