ES4710BD 10 Slots L2/L3/L4 Chassis Switch

Copper Cable/Fiber cable connection

Ethernet cable connection

Fiber cable connection

Power supply connection

2.3.1 Switch Installation

2.3.1.1 Desktop installation

Note:

● Choose a smooth level workbench
● Verify that the workbench is strong enough to support the ES4710BD’s fully configured

weight

● Plan a good position for your ES4710BD that is easy to operate and has an appropriate power

source and grounding point.

● Place the ES4710BD safely on the workbench, avoid obstructions on any side of the switch.

To avoid damage, do not place any weight on the switch.

2.3.1.2 Rack-mounting ES4710BD

Note:

Before mounting the ES4710BD into the rack, verify that the mounting positions of the rack

are correct. Preposition of the mounting points may result in inadequate spacing between the

switch front panel and the rack front door, and the rack front door may be unable to be closed

with cables and fiber cables connected. Please keep a 10 mm spacing between the switch front

panel and the rack front door.

Verify the following before installation: the rack is stably positioned; all modules inside the

chassis are fully installed; no obstructions are present inside or around the rack; the switch is

situated near the rack for ease of installation.

Installation Steps

Step 1: Attach the 2 hangers on the ES4710BD with screws provided in the accessory kit.

Be sure to attach the hangers in the correct direction, otherwise the switch will not be

able to mount into a standard rack.

Note that the hangers are not weight bearing. They are used to fasten the switch. The

mounting Shelf or sliding rails (bolt to the rack) will support the switch.

Notice
