44
E ES4710BD 10 Slots L2/L3/L4 Chassis Switch
Table 1.7 EM4700BD-12GX-SFP port description
Port Type Specification
SFP
z SFP-SX transceiver:
62.5/125 µm multi-mode fiber: 275 m
50.0/125 µm multi-mode fiber: 550m
z
SFP-LX transceiver:
9/125 µm single-mode fiber: 10 km
z SFP-LH-40 transceiver:
9/125 µm single-mode fiber: 40 km
z SFP-LH-70 transceiver:
9/125 µm single-mode fiber: 70 km
z
SFP-LH-120 transceiver:
9/125 µm single-mode fiber: 120 km
1.4.2.3.4 Front Panel – Reset Button
The EM4700BD-12GX-SFP provides a RESET button for resetting the board.
1.4.2.3.5 Front Panel – SWAP Button
The EM4700BD-12GX-SFP provides a SWAP button for hot swapping the module during operation.
Before removing the modules, users should first press the SWAP button. The module will then
prepare for a hot-swap and the system operation indicator (RUN) will turn yellow and blink at 8 Hz.
When the RUN indicator is off, the cards are powered off and can be removed.
1.4.2.4 EM4700BD-2XG-XENPAK
Dual 10GbE fiber line card (EM-7600-2-10GX): supporting 2 10GBase-X fiber port for layer 2 and
layer 3 switching and routing.
1.4.2.4.1 Front Panel
The EM4700BD-2XG-XENPAK provides 2 XENPAK 10Gb fiber transceiver ports, the front panel
view is shown below:
Fig 1-7 EM4700BD-2XG-XENPAK front panel view
