40
E ES4710BD 10 Slots L2/L3/L4 Chassis Switch
Off
Cards are powered off and can be
removed
On (Green) Master Master-Slave
indicator
M/S
Off Slave
On (Green)
Power Supply Module operating
normally
OK
Off
Power supply module malfunctioning
or not present (with Fail off)
On (Yellow) Power Supply Module malfunction
Power
Supply
Module
Status
indicator:
POWER
Fail
Off
Power supply module operating
normally or not present (with OK off)
On (Green) Fan operating normally
OK
Off
Fan malfunctioning or not present
(with Alarm off)
On (Yellow) Fan malfunction
Fan
Assembly
Status
indicator:
FAN
Alarm
Off
Fan operating normally or not present
(with OK off)
1.4.2.1.3 Front Panel – Console Port
The EM4710BD-AGENT provides a RJ-45 (receptacle) Console serial port. Users can connect to
hosts via this port to perform system debugging, configuration, maintenance, administration and
host software loading.
Table 1.2 EM4710BD-AGENT Console description
Property Specification
Connector RJ-45 (receptacle)
Connector type
RS-232
Baud rate 9600bps (default)
Supporting service
z
Connects to character terminals
z
Connects to PC serial port and running terminal emulator on
PC.
1.4.2.1.4 Front Panel – Management Port
The EM4710BD-AGENT provides a RJ-45 (receptacle) Ethernet port. Users can connect through
this administration port to hosts for program loading or to connect to remote devices for remote
administration (e.g., an administrative workstation). Note: when connecting to the host, a cross-over
cable should be used.
Table 1.3 EM4710BD-AGENT administrative port description
