281
E ES4710BD 10 Slots L2/L3/L4 Chassis Switch
12.5.4 Configure standard ACL name configuration and delete the
standard ACL name configuration
Click “ACL name configuration” to open up the sub-sections, next click “ACL name configuration”
to enter the configuration page. The way to configure the “ACL name configuration” is the same
with “Numeric ACL Configuration”. The only difference users should change the ACL number to
the ACL name. This should be entered in ACL name not ACL number. CLI command: 12.2.2.6
There are seven sub-sections of this:
z ACL name
z ACL type － standard and extended
z Rule － permit and deny
z Source address type － Specified IP address or any randomly allocated IP address Source IP
address
z Reverse network mask
z Operation type －Add or Remove
To add a numeric ACL, specify the ACL name and related value, select the “add” in the Operation
type and then click “Apply”.
