10 Networking
10.1 Network system configuration
Using the layout pane, the EHX operator can create, delete, or edit matrices for a
particular matrix system. From this screen the EHX operator can also allocate
configurations to Eclipse HX matrices, clear configurations and upload active current
configurations.
The layout screen also allows the management of Intelligent Linking Trunks. This is
explained in 10.2 Intelligent linking (trunking).
10.1.1 Configuration passwords
Individual configurations can be password protected to prevent unintended or
unauthorized changes to be made or the configuration to be downloaded to a matrix.
1) To set the password on the current configuration select the matrix on the layout
pane, and open the Configuration Manager.
Figure 10-1 Opening the Configuration Manager
When the Configuration Manager is open the properties of any of the available
configurations (on that matrix) can be viewed and edited.
Figure 10-2 Configuration Properties Dialog
