DS3170 DS3/E3 Single-Chip Transceiver
208 of 233
13 PIN CONFIGURATIONS
Table 13-1. DS3170 Pin Assignments for 100-Pin LQFP (Sorted by Signal Name)
SIGNAL PIN SIGNAL PIN SIGNAL PIN SIGNAL PIN
A[0] 37 D[7] 47 ROH 88 TXP 12
A[1] 27 D[8] 48 ROHCLK 73 TXP 13
A[2] 28 D[9] 40 ROHSOF 61 WIDTH 23
A[3] 29 GPIO[1] 68 RPOS 62 WR 5
A[4] 30 GPIO[2] 65 RSER 86 UNUSED 89
A[5] 31 GPIO[3] 64 RSOFO 80 VDD 3
A[6] 33 GPIO[4] 57 RST 74 VDD 9
A[7] 35 GPIO[5] 49 RXN 97 VDD 34
A[8] 36 GPIO[6] 39 RXP 94 VDD 51
ALE 32 GPIO[7] 8 SPI 4 VDD 69
NC 20 GPIO[8] 7 TCLKI 72 VDD 84
CS 1 HIZ 95 TCLKO 77 VDD_CLAD 21
D[0] 38 INT 71 TEST 24 VDD_JA 11
D[1] 50 JTCLK 91 TLCLK 85 VDD_RX 93
D[10] 52 JTDI 96 TNEG 70 VDD_TX 15
D[11] 53 JTDO 90 TOH 83 VSS 6
D[12] 54 JTMS 98 TOHCLK 82 VSS 26
D[13] 55 JTRST 99 TOHEN 66 VSS 41
D[14] 56 MODE 18 TOHSOF 60 VSS 59
D[15] 58 RCLKO 87 TPOS 67 VSS 76
D[2] 42 RD 2 TSER 75 VSS 100
D[3] 43 RDY 25 TSOFI 78 VSS_CLAD 19
D[4] 44 REFCLK 22 TSOFO 79 VSS_JA 10
D[5] 45 RLCLK 81 TXN 16 VSS_RX 92
D[6] 46 RNEG 63 TXN 17 VSS_TX 14
