Rainbow Electronics DS26502 User Manual
General description, Applications, Ordering information

1 of 125
REV: 070904
Note: Some revisions of this device may incorporate deviations from published specifications known as errata. Multiple revisions of any device
may be simultaneously available through various sales channels. For information about device errata, clic
GENERAL DESCRIPTION
The DS26502 is a building-integrated timing-
supply (BITS) clock-recovery element. The
receiver portion can recover a clock from T1,
E1, 64kHz composite clock, and 6312kHz
synchronization timing interfaces. In T1 and E1
modes, the Synchronization Status Message
(SSM) can also be recovered. The transmit
portion can directly interface to T1, E1, or
64kHz composite clock synchronization
interfaces as well as source the SSM in T1 and
E1 modes. The DS26502 can translate between
any of the supported inbound synchronization
clock rates to any supported outbound rate. A
separate output is provided to source a 6312kHz
clock. The device is controlled through a
parallel, serial, or hardware controller port.
APPLICATIONS
BITS Timing
Rate Conversion
ORDERING INFORMATION
PART TEMP
RANGE
PIN-PACKAGE
DS26502L
0°C to +70°C
64 LQFP
DS26502LN -40°C to +85°C 64 LQFP
FEATURES
§
G.703 2048kHz Synchronization Interface
Compliant
§
G.703 64kHz Centralized (Option A) and
Codirectional Timing Interface Compliant
§
G.703 Appendix II 64kHz and 6312kHz
Japanese Synchronization Interface
Compliant
§
Interfaces to Standard T1/J1 (1.544MHz) and
E1 (2.048MHz)
§
Interface to CMI-Coded T1/J1 and E1
§
Short- and Long-Haul Line Interface
§
Transmit and Receive T1 and E1 SSM
Messages with Message Validation
§
Crystal-Less Jitter Attenuator with Bypass
Mode
§
Fully Independent Transmit and Receive
Functionality
§
Internal Software-Selectable Receive- and
Transmit-Side Termination for
75Ω/100Ω/110Ω/120Ω T1, E1, and
Composite Clock Interfaces
§
Monitor Mode for Bridging Applications
§
Accepts 16.384MHz, 8.192MHz, 4.096MHz,
or 2.048MHz Master Clock
§
64kHz, 8kHZ, and 400Hz Outputs in
Composite Clock Mode
§
8-Bit Parallel Control Port, Multiplexed or
Nonmultiplexed, Intel or Motorola
§
Serial (SPI) Control Port
§
Hardware Control Mode
§
Provides LOS, AIS, and LOF Indications
Through Hardware Output Pins
§
Fast Transmitter-Output Disable Through
Device Pin for Protection Switching
§
IEEE 1149.1 JTAG Boundary Scan
§
3.3V Supply with 5V-Tolerant Inputs and
Outputs
DS26502
T1/E1/J1/64KCC BITS Element
www.maxim-ic.com
Document Outline
- FEATURES
- SPECIFICATIONS COMPLIANCE
- BLOCK DIAGRAMS
- PIN FUNCTION DESCRIPTION
- Transmit PLL
- Transmit Side
- Receive Side
- Controller Interface
- Interrupt/JA Clock Source Select 1
- Data Bus D[7] or Address/Data Bus AD[7]/Transmit Termination Select
- Data Bus D[6] or Address/Data Bus AD[6]/Transmit Termination Select
- Data Bus D[3] or Address/Data Bus AD[3]/TS_8K_4 Mode Select
- Data Bus D[1] or Address/Data Bus AD[1]/Receive Mode Select 3/Master Out-Slave In
- Data Bus D[0] or Address/Data Bus AD[0]/Transmit Clock Source Select 0/Master In-Slave Out
- Address Bus Bit A[6]/MCLK Prescale Select
- Address Bus Bit A[3]/Line Build-Out Select 1
- Address Bus Bit A[2]/Line Build-Out Select 0
- Address Bus Bit A[1]/Transmit AIS
- Address Bus Bit A[0]/E1 Termination Select
- Bus Type Select/Transmit and Receive B8ZS/HDB3 Enable
- Read Input-Data Strobe/Receive Mode Select Bit 2
- Chip Select/Remote Loopback Enable
- Write Input (Read/Write)/Transmit Mode Select 3
- JTAG
- Line Interface
- Power
- PINOUT
- HARDWARE CONTROLLER INTERFACE
- PROCESSOR INTERFACE
- T1 FRAMER/FORMATTER CONTROL REGISTERS
- E1 FRAMER/FORMATTER CONTROL REGISTERS
- I/O PIN CONFIGURATION OPTIONS
- T1 SYNCHRONIZATION STATUS MESSAGE
- E1 SYNCHRONIZATION STATUS MESSAGE
- LINE INTERFACE UNIT (LIU)
- LOOPBACK CONFIGURATION
- 64kHz SYNCHRONIZATION INTERFACE
- 6312kHz SYNCHRONIZATION INTERFACE
- JTAG BOUNDARY SCAN ARCHITECTURE AND TEST ACCESS PORT
- FUNCTIONAL TIMING DIAGRAMS
- OPERATING PARAMETERS
- AC TIMING PARAMETERS AND DIAGRAMS
- REVISION HISTORY
- PACKAGE INFORMATION
