PRODUCT PREVIEW
DS3181,2,3,4 Multi-Port ATM/Packet PHYs
For DS3/E3 with Built-In LIUs
FEATURES
• Quad (DS3184), triple (DS3183), dual
(DS3182) or single (DS3181) with integrated
LIU ATM / Packet PHYs for DS3 and E3
• Each port independently configurable
• Performs receive clock/data recovery and
transmit wave shaping
• Jitter attenuators can be placed either in the
receive or transmit paths
• Interfaces to 75Ω coaxial cable at lengths up
to 380 meters or 1246 feet (DS3) or 440
meters or 1443 feet (E3)
• Uses 1:2 transformers on both Tx and Rx
• Requires minimal external components
• Universal PHYs map ATM cells and/or
HDLC packets into DS3 or E3 data streams
• UTOPIA 2 or 3 or POS-PHY 2 or 3 interface
with 8, 16, or 32 bit bus width up to 66 MHz
• Ports independently configurable for cell or
packet traffic in POS-PHY bus modes
• Direct, PLCP and clear-channel cell mapping
• Direct and clear-channel packet mapping
• On-chip DS3 (M23 or C-bit) and E3 (G.751
or G.832) framers
• Ports independently configurable for DS3, E3
or arbitrary framing protocol up to 52 Mbps
• Programmable (externally controlled or
internally hardware based engine) subrate
DS3/E3 circuitry
• Full featured DS3/E3/PLCP alarms
• Built-in HDLC controllers with 256 byte
FIFOs for DS3 PMDL, G.751 Sn bit or G.832
NR/GC bytes
• On-chip BERTs for PRBS and repetitive
pattern generation, detection and analysis
• Large performance-monitoring counters for
accumulation intervals up to 1 second
• Flexible overhead insertion/extraction ports
for DS3, E3 and PLCP framers
• Loopback include line, diagnostic, framer
payload and system interface
• Ports can be disabled to reduce power
• Integrates clock rate adapter to generate the
required 44.736 MHz for DS3, 34.368 MHz
for E3, and/or 52 MHz for arbitrary framing
protocol up to 52 Mbps
• 8/16-bit generic microprocessor interface
• Low power 3.3V operation (5V tolerant I/O)
• Small high-density Thermally Enhanced (TE)
Chip Scale BGA packaging
• Industrial temperature range: -40 to +85°C
•
IEEE 1149.1 JTAG test port
www.maxim-ic.com/telecom
.
Rev 1.5
1 of 13
022304
