EVS

Multicam - User Manual

Version 9.00

EVS Broadcast Equipment SA – March 2008

70

L

OCAL

This function allows the user to reconnect to the local LSM after having
accessed distant clips or record trains. The function is highlighted when the
user is connected to both clips and record trains on the local LSM. It is
displayed only on Master/Server LSMs when they are connected to the SDTI
network.

S

YNC

P

RV

This option allows the user to synchronize the PRV with the time code and
speed of the PGM output. This function is not available with remote record
trains.

2

ND

CTRL

This function allows the operator to swap the control of one or several play
channels between the EVS Remote panel and a third-party controller using
the Sony BVW75 or XtenDD35 protocol. Both controllers receive
permanently the status of the channel(s), but only one controller at a time is
able to actually control a channel. The secondary controllers are defined in
Section 7 of the Remote Setup menu.

Press this function to enter the 2nd CTRL menu, select the channels that
you want to pass to the secondary controller by pressing the corresponding
A or B key, then press D (DONE) to validate your selection. Do the same to
bring the control of a channel back to the EVS remote.
