an eraser. This facility remains «on». When no longer required, select E
again to disable it and return to the previous active drawing mode.

C

LEAR

(C)

Selecting C on the Paint Mode monitor display allows clearing of the entire
drawing. Once selected, you can choose between 3 options: Clr to clear,
DfC to define customized colours or you may escape (ESC) this function
without clearing any drawing.

If you select Define Colour (DfC), a new screen will appear including a U-V
selection area, and an Y level selection area. Select first the colour you
want to edit on the top of the screen, then select the U-V and Y values by
moving the pen on the right location of each selection area. When the
adjustment is made, move the pen to an empty zone of the screen.

The CLEAR function is also available form the Remote panel (SHIFT + B)
No confirmation is required.

K

EYER

(K)

Can be selected with the pen, click on K (arrows appear/disappear) on the
Paint Mode monitor display, or press SHIFT + A on the Remote panel menu.
This feature will cause the drawing to dissolve on and off using the dissolve
duration defined in the Setup menu (Page 1, F6)

L

IBRARY

(L)

Selecting L allows entering into a library where the user can load or save
entire drawings and logos.
