2.5 TRANSPORT CONTROLS
2.5.1 JOG DIAL
The JOG DIAL allows the operator to pass into Search mode and
thus to choose exactly the Short OUT or Short IN image. Move the jog dial
clockwise to search forward and move it counter-clockwise to search
backwards. One revolution of the jog dial will produce a jump of
approximately 35 frames. This number can be multiplied by enabling the
Fast mode. The multiplication factor is defined in the Setup menu.
Note
The jog dial is also used:
• to set parameters in the Setup menu.
Refer to the Setup menu section for more information.
• to browse inside the clips database, the cue points or the
current playlist.
Refer to the explanation of the BROWSE function for more
details.
The jog dial is active at all times when the system is in Play & Record
modes.
