The following parameters can be defined:
IN LOOP
D-VITC The TC and user bits are always written on the monitoring SD
outputs of the record codec and are the same as on the
source video.
Lines Lines on which the VITC time code must be written on the
loop of the input.
By default, these are lines 14-16 in NTSC and 19-21 in PAL.
HD OUT
HANC LTC Field to specify if embedded time code has to be inserted in
the output. The value specified has to be the same as for the
HANC VITC field.
The possible values are:
No No new time code inserted in the output.
In (default) Same time code as in the input inserted in
the output.
LTC Time code from the LTC table inserted in
the output.
USER User-defined time code inserted in the
output.
UserBits Yes/No flag to specify if the user bits have to be inserted in
the output. The default value is ‘Yes’.
HANC
VITC
Field to specify if embedded time code has to be inserted in
the output. The value specified has to be the same as for the
HANC LTC field.
The possible values are:
No No new time code inserted in the output.
In (default) Same time code as in the input inserted in
the output.
LTC Time code from the LTC table inserted in
the output.
USER User-defined time code inserted in the
output.
