EVS

Multicam - User Manual

EVS Broadcast Equipment SA – March 2008

Version 9.00

177

C (clear)

clears screen

L

enables line mode («one-shot»). See also Section 0.

C / c (circle)

selects large / small circle («one-shot»). See also Section
0.

A

automatic arrow at end of freehand drawing. See also
Section 0.

D

selects brush colour and thickness. See also Section 0.

Br1 / Br2

toggles between Brush1 and Brush2.

E

erases unwanted portion of graphic. See also Section 0.

k / >k<

keyer off / on. See also Section 0.

L

calls the Library module where drawing, logos, …

can be saved.

C

marks CUE OUT point on current clip

S

plays back the clip at slow motion speed. The speed of
slow motion is predefined in the PGM Speed item from the
Setup Menu (Page2 – F3)

P

plays back the current clip at normal speed

The clip countdown displays the field time. This means that the countdown
matches the slow motion speed.

Note

Selecting C (clear) from the monitor enters the Clear menu and the
DFC menu. DFC menu allows you to select the brush colour from a
YUV colour palette

If working in network mode, painting can be performed on remote clips as
well as on local clips.

S

TRAIGHT

L

INE

/

B

ROKEN

L

INE

D

RAWING

(L)

Select L on the Paint Mode monitor display. You will then be prompted to
enter the first point of the line.

Place the pen at the start point and press lightly. Then place the pen at the
next point and press lightly again. A straight line appears to connect these
2 points. Repeat this as many times until the line is complete, then place
the pen over the “ESC” area in the top right corner of the OSD and press
lightly. The system automatically defaults back to freehand drawing mode.

C

IRCLE

D

RAWING

(O)

Select this menu to draw circles.

A menu allows you to choose between the following options:
