EVS
Multicam - User Manual
EVS Broadcast Equipment SA – March 2008
Version 9.00
35
4.12
CONTROLLER AND PROTOCOL
SETTINGS
Port Device/Protocol p.7.1
RS422 #1 EVS Remote [F7]ID Type:
[F2]RS422 #2 EVS Remote ID LSM
[F3]RS422 #3 EVS Remote
[F4]RS422 #4 Sony BVW75
[F5]RS422 #5 Sony BVW75
[F6]RS422 #6 Touch Screen
[Menu]Quit [Clr+F_]Dft [F9]PgUp [F0]PgDn
This page is used to define what type of device/controller is connected to
each RS422 port of the XT[2].
4.12.1
RS422
#1
Value: EVS Remote
When working in LSM base configuration, the first RS422 port must always
be connected to an EVS remote. No other possible selection
4.12.2
RS422
#2
Possible values: EVS Remote, Sony BVW75, XtenDD35, Odetics, VDCP,
EVS AVSP, EVS IPDP, Edit Rec, ---------
Default: EVS Remote
4.12.3
RS422
#3
Possible values: EVS Remote, Sony BVW75, XtenDD35, Odetics, VDCP,
EVS AVSP, EVS IPDP, Edit Rec, ---------
Default: EVS Remote
