EVS Multicam - User Manual
EVS Broadcast Equipment SA – March 2008
Version 9.00
185
PGM1 CAM A *PGM2* CAM B
Aud.Met. PgmSpd Sort->TC PostRoll
Sw to IN Search Pref
P.1 B.1 Clips: LOCAL Records: LOCAL
PL 11: <
Msg:
V Split Swap Sync
Left Right L & R SHIFT
17. Split Screen mode
The Split Screen mode, which is a software option, allows a simple split
screen effect on PGM 1. This mode operates very similar to the 2PGM
mode, except that the two outputs are now left and right parts of the screen
(vertical split screen) or top and bottom part of the screen (horizontal split
screen) or mixed together on the entire screen (Split Mix mode). The Split
mode also allows for DVE-like adjustment of the video within the split effect,
for optimum positioning of the material.
17.1.1 V
ERTICAL
S
PLIT
Press the SHIFT key (D) to switch between normal and special commands:
Command Description
LEFT To control the left part of the monitor
RIGHT To control the right part of the monitor
L & R To control both sides together
SHIFT Access / Exit special commands
Å LF Æ To centre the left picture
Å RG Æ To centre the right picture
Å WP Æ To move the separation line
V SPLIT /
H SPLIT
Toggles between horizontal and vertical Split screen menus
SWAP To swap sources from both sides
V Split Swap Sync
<-Lf-> <-Rg-> <-WP-> SHIFT
