EVS

Multicam - User Manual

Version 9.00

EVS Broadcast Equipment SA – March 2008

160

13.5.2.3

D

ISPLAYED

I

NFORMATION

OSD

I

NFORMATION

The following information is displayed on the OSD:

• Total timeline duration

• For each track: current clip ID, remaining time, relative position in the

track

• Timeline control track time code (starting at 10:00:00:00)

*TL13* [EDIT] 00:19:22

V * 112B 00:00:25 01/02

A1* 113B 00:02:25 02/03

A2* 113B 00:02:25 02/03

■■■ ■■

■■ ■

10:00:00:00

112B

LCD

I

NFORMATION

The same information is displayed on the Remote panel with the current
time code of the clip in addition.

The ABCD Soft keys on the Remote are as follows:

Video

Audio 1 Audio 2

The highlighted keys show on which track the insert and extend actions will
be carried out. In other words, if video only is selected when users do an
insert, only the video will be inserted.

13.5.2.4

M

ARKING

IN

AND

OUT

P

OINTS ON THE

R

ECORDER

The operators can mark IN and OUT points anywhere on the recorder as in
the Replace mode: the timeline is equivalent to a record train.

E

XTEND

Once an IN and an OUT points have been marked on the recorder, the
Extend function becomes available on the D key of the Remote panel.

Video

Audio 1 Audio 2 Extend
