EVS Multicam - User Manual Version 9.00
EVS Broadcast Equipment SA – March 2008
22
“Keyword Management”.
4.7.8 K
EYWORD
M
ODE
Possible values: List (default), Numeric
This parameter specifies the keyword assignment/search mode on the EVS
Remote panel:
• List: It will display the keywords by groups of 8 on the LCD of the
Remote panel and the operator can select them with the corresponding
F_ key.
• Numeric: It doesn’t display the keywords list on the LCD, but allows the
operator to enter directly the keyword ID using the F_ keys. The
Numeric mode is faster when the operator knows the position of the
keywords inside the keywords file, either from memory, using the VGA
keyword screens, or using a print of the keywords list.
4.7.9 PUSH M
ACHINE
1 & 2
Possible values: network system name and number. Default: -------- #--
This parameter specifies which machine(s) on the network clips must be
sent to when using the PUSH function on the EVS Remote panel. Users can
define two push machines: (F3): PUSH Machine 1, (F4): PUSH Machine 2.
The clips will be pushed in sequential order.
4.7.10 PUSH R
ECEIVE
P
AGE
Possible values: Select one or more clip pages from 1 to 10. Default: p.5
This parameter specifies the page of your machine where clips sent to you
by other network operators using the PUSH function must be stored.
How to Specify PUSH Receive Page(s)
To specify the page(s) to which the clips pushed from another network
operator will be stored, proceed as follows:
1. In the 2 n d page of Clip parameters, press the F5 key to edit the PUSH
Receive Page parameter.
2.
Press the F_ key corresponding to the page number you want to
select/unselect as PUSH Receive Page.
The selected pages will be highlighted on the LCD and the
corresponding F_ keys light red. F_ keys of unselected pages light
green.
