EVS Multicam - User Manual
EVS Broadcast Equipment SA – March 2008
Version 9.00
183
T Select the darkness of the background (8 choices)
S Select the size of the circle (8 choices)
E Select the border thickness (8 choices)
C Select the border colour (8 choices)
Indicates a keyframe has been marked on current
field.
E Erases currently displayed keyframe
R Erases all keyframes in the current clip.
Z Toggles between Zoom, Static Zoom and normal
highlight.
M Allows you to mark a keyframe directly from the touch
screen or from the tablet. If this option is active,
touching a point on the screen automatically creates
the keyframe. This option becomes inactive after each
keyframe creation.
C Marks CUE OUT point on current field
S Starts slow-motion (preset in Prg Spd)
P Plays back the current clip
<<< >>> Searches the material (clip or live recording). A single
click with the stylus move one frame forward or one
frame back
Z
OOM
O
PTIONS
On the Remote panel display, selecting the Zoom option (soft key A) on the
Remote will cause the tracking object to be changed to the Zoom function.
Thee circle will magnify 4x the highlighted area of the image. This is a great
feature for showing, for example, a close call like a foot on a line or a ball
in/out of bounds.
Note
The dissolve effect is not available when using the Zoom effect.
The T, S, E and C parameters are not available either in Zoom
mode.
Selecting Zoom again will switch to Static Zoom mode. Keep in mind, when
selecting the Zoom option, the software will take a few seconds to apply the
change.
The Static Zoom allows the user to zoom an area of the picture via a picture
in picture display.
