Multicam - User Manual

EVS Broadcast Equipment SA – March 2008

Version 9.00

39

Special Control Settings p.7.5

Control type OSD Display

PGM5:[F1]Exclusive [F5] Main

[Menu]Quit [Clr+F_]Dft [F9]PgUp [F0]PgDn

This page is the same as Page 7.4, but assigns PGM5

4.14

GPI IN SETTINGS

GPI In Settings p.8.1

GPI# Channel/Device Port Function

1 [F1]PGM1 -- [F5]Play

2 [F2]PGM2 -- [F6]Play

3 [F3]PGM3 -- [F7]Play

4 [F4]PGM4 -- [F8]Play

[Menu]Quit [Clr+F_]Dft [F9]PgUp [F0]PgDn

GPI In Settings p.8.2

GPI# Channel/Device Port Function

5 [F1]RMT1 -- [F5]Play

6 [F2]RMT1 -- [F6]Next

7 [F3]RMT1 -- [F7]Skip

8 [F4]RMT1 -- [F8]Pause

[Menu]Quit [Clr+F_]Dft [F9]PgUp [F0]PgDn

These 2 pages define the settings for the GPI inputs of the XT[2] server.
For each GPI input, the operator has the possibility to define the following
parameters:

• Channel that the GPI will affect or the device that the GPI is assigned

to.

A device can be an EVS Remote #1 or one of the protocols defined in
page 7.1 (if some GPI must be used by the AirBox in a mixed
configuration LSM+AirBox, or if a GPIs must trigger some actions on a
channel controlled by a Sony protocol, etc.). If the operator selects EVS
Remote #1, the GPI will trigger the selected action on all channels
controlled by that remote.
