EVS

Multicam - User Manual

Version 9.00

EVS Broadcast Equipment SA – March 2008

184

In the Static Zoom mode, at the bottom left of the screen, a “P” appears on
the OSD to define the position of the static zoom.

Just click on the P and move the cursor to indicate where the static zoom
should be.

K

EYFRAME

I

NFORMATION

D

ISPLAY

On the OSD, a second line is added to indicate the number of keyframes
marked and the position of the current keyframe.

The information displayed can be interpreted as follows:

Display Meaning

---/---

No keyframes are defined.

---/021

21 keyframes are defined but the user is not on a
keyframe

012/021

21 keyframes are defined and the user is on
keyframe 12 of 21.

T

RANSPARENCY

O

PTIONS

Select the last choice in the transparency options to set the background in
black and white.
