The Setup menu, on page 6.3, displays the following screen:
Mapping network cam p.6.3
[F1]Authorize cam mapping: Yes
Cam A : Local
Cam B : Local
[F3]Cam C : CamA/01
[F4]Cam D : CamB/01
[Menu]Quit [Clr+F_]Dft [F9]PgUp [F0]PgDn
The F1 key allows the user to enable or disable the option.
The other F_ keys allow the user to perform the mapping:
• If the camera is local (cam A and B on the example), no F_ key is
assigned to it.
• If the position is free and can be used by a network camera, the F_ key
is available: The F2 to F4 keys can be assigned to respectively Cam B,
C or D in this case depending on the configuration defined in the Setup.
To map a distant camera to a local camera position, select the cam position
with the corresponding F_ key and jog with the dial to reach the desired
network camera to map.
The clipping on mapped cameras follows the same rule as for local
cameras. Clips created will be copied as local clips in the corresponding
positions.
Two limitations must be noted in the mapped camera mode:
• All cameras are delayed so that in LIVE mode all cameras are on the
same time code.
• Recalling local clips will not be instantly available: the network copy of
the remote cameras will occur before the clip can be recalled.
