EVS

Multicam - User Manual

EVS Broadcast Equipment SA – March 2008

Version 9.00

13

4.5

OSD SETTINGS

OSD Settings p.1.1

[F1]Genlock Error Msg: Yes

[F2]Disk Error Msg : Yes

[F3]Network Error Msg: Yes

[F4]Cue number on OSD: Yes

[F5]Keyword info : No

[Menu]Quit [Clr+F_]Dft [F9]PgUp [F0]PgDn

4.5.1

G

ENLOCK

E

RROR

M

SG

Possible values: Yes (default) / No

This function enables or disables the Genlock information on the output
monitor. If Genlock reference is not correct, the !GkV message appears on
the output monitor.

4.5.2

D

ISK

E

RROR

M

SG

Possible values: Yes (default) / No

This function displays an error message (!Dsk) on the output monitor when
a disk is faulty.

Note

The XT[2] is equipped with a RAID disk array. This means that the
operation can continue seamlessly even with 1 faulty disk. If 1 disk
is disconnected during operation, the “!Dsk” message appears on
all output monitors, and another message appears when the
operator shuts down the application, to invite him to replace the
disk and rebuild the RAID array.

Refer to the Technical Reference manual for details on the RAID
system and its maintenance.

4.5.3

N

ETWORK

E

RROR

M

SG

Possible values: Yes (default) / No

This function displays an error message (!Net) on the output monitor when
the network connection is faulty and another message (ÆNet) when the
network becomes available again and the system is trying to re-connect.
