EVS

Multicam - User Manual

EVS Broadcast Equipment SA – March 2008

Version 9.00

55

IN

This function defines the IN point of a clip. The key will light differently
depending in the following situations:

Green key

The key lights green if an IN point exists but is not the
image you see.

Red key

The key lights red if the on-air image is at this IN point.
This point can be entered while recording.

Flashing

(green or

red) key

In Split Audio mode, this key can be flashing green or
flashing red. Refer to the section 13.2 “Split Audio Mode”,
on page 143 for more details.

OUT

This function defines the OUT point of a clip. This operates similarly to the
IN button.

Note

The OUT point (field) is always excluded. When playing a clip, it
will freeze on the field preceding the OUT point marked by the
operator.

M

ODIFICATION OF

C

LIP

IN

/

OUT

P

OINTS

Select the clip that you wish to modify, use the jog dial to position the
material at the new IN or OUT point, and re-mark the IN or OUT point(s) as
required.

Important

When IN/OUT points are set and a clip is saved, the system
automatically write-protects a user definable length of material
before and after the IN/OUT points respectively. These are
referred to as the guardbands. Their duration can be set in the
Setup menu under «Guardbands» (page 2, F2) as required.

The duration of the guardband after the OUT point can be reduced
according to the quantity of video/audio material available when
saving the clip.

JOG

KNOB

This function is used to accurately cue material.

FAST

JOG

When selected, this option enables fast picture search: the actual speed of
this fast jog is adjustable in the Setup menu. Starting a play or returning to
E2E mode resets the Fast Jog mode.
