EVS

Multicam - User Manual

EVS Broadcast Equipment SA – March 2008

Version 9.00

33

4.11.6

R

ECALL CLIP TOGGLE

Possible values: Enable (default) / Disable

This option allows the operator to select the camera of a clip through the
Function keys. Pressing several times the F_ key browses to CAM A, CAM
B, CAM C, CAM D, CAM E and CAM F.

EVS Controller p.6.2

[F1]Record key : Start REC + Live

[F2]Pointing device : Tablet

[F3]VGA & RMT Sync : No

[F4]PGM/PRV Mode : Enable

[Menu]Quit [Clr+F_]Dft [F9]PgUp [F0]PgDn

4.11.7

R

ECORD

K

EY

Possible values: Start REC+Live (default) / Live

This parameter changes the function of the RECORD key on the remote:

Start REC+Live: Pressing the RECORD key starts the record process

and switches to LIVE mode.

Live: Pressing the RECORD key only switches to last recorded picture,

but the record is not restarted if it has been previously stopped by the
operator.

4.11.8

P

OINTING

D

EVICE

Possible values: Tablet (default) / Touch Screen

This setting initializes the Tablet or the Touch Screen. If the tablet is not
properly calibrated, use this function to re-initialize it. If using the Touch
Screen, this one must always be connected to RS422 port #6 of the XT[2],
and defined as such at page 7.1 of the setup.

4.11.9

VGA

&

RMT

S

YNC

Possible values: No, Yes, Server Nbr

This parameter selects whether and how the current clips machine, page
and bank of VGA screens and EVS Remote panel must be synchronized.
