126

12.5

SEARCHING THE DATABASE USING
THE EVS REMOTE PANEL

Keywords and ranking assigned to clips can be used to search the clips
database.

When the current element on the primary channel is a record train, the
Search function is directly available from the C position in the secondary
menu. To call it, press MENU to enter the secondary train menu, then press
once the C key.

When the current element on the primary channel is a clip, the Search
function is still available from the same location, but it is “hidden” behind
the Name function. To call it in this case, press MENU to enter the
secondary clip menu, then press twice the C key.

In both cases, the LCD display becomes (in LIST mode):

EYWORDS

They can be selected for use as search criteria the same way they were
selected to be assigned to a clip, in LIST or NUMERIC mode. Up to 3
keywords can be selected as search criteria. If all 3 keywords locations are
used, some of them must be cleared before selecting a new keyword. Press
CLEAR + F1 / F2 / F3 to clear to corresponding keyword location.

ANKING

A ranking can also be used as the only search criteria, or can be combined
to the keywords as an additional criterion. Press the B key several times to
select the desired ranking.

The RESET key (SHIFT+A) can be used at any time to clear all 3 keyword
locations and reset the ranking to the lowest level.

keyword89012

2 keyword89012

keyword89012

F1:action_1 F6:action_6

F2:action_2 F7:action_7

F3:action_3 F8:action_8

F4:action_4 F9:Prev.page

p.01

F5:action_5 F0:Next page

Reset
