EVS

Multicam - User Manual

Version 9.00

EVS Broadcast Equipment SA – March 2008

44

5. SETUP Module

The Setup Configuration module, also called VGA Setup screen in this
manual, and in the user interface, aims at configuring the Multicam software
and defining server settings in relation to time codes, protocol
communication, etc.

This module contains several pages, i.e. windows, some of which are
described shortly or in depth in this section.

The following table presents the windows and settings covered in this
section:

Page 1

See Section 5.1.

It includes several general settings on:

• the time codes

• the OSD

• the VGA

• the network

• the clip management

• the record trains

• the channel names

Page 2

See Section 5.2

It includes detailed settings on the insertion of VITC
or ANC time codes, channel by channel.

Note

The other windows are described in the Software Technical
Reference manual on XT[2] Servers.

H

OW TO

A

CCESS THE

S

ETUP

C

ONFIGURATION

The VGA Setup screen is available by pressing simultaneously SHIFT-F2 on
the keyboard with CAPS LOCK disabled. The Setup Configuration is not
accessible if CAPS LOCK is ON.

H

OW TO

M

OVE

I

NSIDE THE

S

ETUP

C

ONFIGURATION

• Use / SHIFT- to move from one parameter to the

next/previous, and the ←/→ arrow keys to change the value of a
parameter.

• Use PAGE UP / PAGE DOWN to access the Time code configuration

screen.
