Additional parameters are available for the external loop:
• With the Cam A function (SHIFT+C), you can select the camera the PGM
will be recorded to for the external LOOP process. Press SHIFT+C until
the desired camera is selected.
• With the +2 fields function (SHIFT+D), you can select by how much the
video coming back to your record channel will be delayed. If you are
using a DVE, it could introduce a delay. This system is based on the
assumption that audio and video are in sync when they hit the record
channel. The delay value can not be negative.
Select SHIFT+D to highlight the delay value and the display allows you
to add frames or fields of delay to the delay value. Pressing either
MENU or SHIFT+D will leave this mode.
13.4.4 R
EPLACE
P
LAYBACK
M
ODE
When the IN and OUT points have been marked, the Int Loop and the Ext
Loop keys are blinking.
Pressing one of the two keys activates the Replace Playback Mode: the
playlist is cued before the IN point (to create guardbands), ready to be
initiated.
A message appears on Remote: “Start Replace: lever or play
button”.
The play can be activated by pressing the PLAY button or moving the lever.
The playlist is played at the speed defined in the playlist but the lever can
also be used to vary the playback speed.
When the Protect OUT point of the clip is reached, a clip containing the IN
and OUT point with the guardbands is created on the Receive page defined
in the Setup menu. The loop is stopped and the user switches back to match
frame edit mode.
A confirmation message pops-up:
Replace in/out by clip xxx ?
MENU: Cancel – ENTER: OK.
If the operator presses ENTER, the material between the IN and OUT points
is replaced with the newly created clip. The playlist returns to Playlist Edit
mode, positioned at the end of the inserted clip.
If the user cancels the operation, the playlist remains in Replace Edit mode.
