Internal Read Only Tags G–3
Publication 2711-6.0
DH-485 Tags
Tag Name Data Type Value Range Description
@Read_BaudRate Unsigned Integer 1 to 4 1 = 1200, 2 = 2400, 3 = 9600, 4 = 19200
@Read_MaxNodeAddress Unsigned Integer 1 to 31
@Read_MemCardStatus Unsigned Integer 0 to 3 0 = Valid memory card format
1 = Incorrect memory card format
2 = No memory card installed
3 = No applications on memory card
@Read_NodeAddress Unsigned Integer 0 to 31
@Read_SerCommStatus Unsigned Integer 0 to 5 0 = Communication link is ok
1 = PanelView terminal is off the link
2 = Scanned node not found
4 = I/O error (Invalid I/O form controller)
5 = Duplicate node address
Remote I/O Tags
Remote I/O Tag Name Data Type Value Range Description
@SRIO_RackNumber Unsigned Integer 0 to 62
@SRIO_RackSize Unsigned Integer 0 to 3 0 = 1/4
1 = 1/2
2 = 3/4
3 = Full
@SRIO_DataRate Unsigned Integer 0 to 2 0 = 57.6K
1 = 115.2K
2 = 230.4K
@SRIO_Module Unsigned Integer 0 to 3 0 = Module Group 0,1
1 = Module Group 2,3
2 = Module Group 4,5
3 = Module Group 6,7
@SRIO_LastRack Unsigned Integer 0 or 1 0 = False
1 = True
@SRIO_BlockTransferReadEnable Unsigned Integer 0 or 1 0 = Disable
1 = Enable
@SRIO_BlockTransferWriteEnable Unsigned Integer 0 or 1 0 = Disable
1 = Enable
@SRIO_BlockTransferTimeout Unsigned Integer 0 to 65535 0 = No Timeout
1 to 65535 (in milliseconds)
@SRIO_PassThruEnabled Unsigned Integer 0 or 1 0 = Disable
1 = Enable
@Read_SerCommStatus Unsigned Integer 1 to 128 1 =Communications active
2 =Timeout in block transfer write from PLC
4 =Timeout in block transfer read
8 =Timeout in both block transfer write and block transfer read
16 =PLC offline
17 =Pass-Through occurring
32 =Communication with PLC failed
64 =Bad rack setup
128= PanelView RIO hardware failed startup tests failed
