2–10 Installation
Publication 2711-6.0
In Windows 95 or Windows 3.x, use the INTERCHANGE Device
Configuration Utility to configure communication drivers that your
computer requires to transfer applications using Pass-Through. This
utility lets you:
•
View active communication drivers
•
Select and configure a communication driver
•
Edit a communication driver
•
Remove a communication driver
•
Access advanced driver parameters
The utility automatically updates the CFG_KT.INI, ABICRUN.BAT,
ABICSTOP.BAT, and the SYSTEM.INI files when drivers are
added, configured and removed.
To transfer applications using a Pass-Through connection, you must
first configure the appropriate driver.
To transfer applications using a serial connection (Internal DF1
driver), memory card or DOS file (using the PanelView File Transfer
Utility for DH-485 terminals), INTERCHANGE software is not
required.
To access the INTERCHANGE Device Configuration Utility:
•
In Windows 95, click the Start button, click Programs, click
PanelBuilder, then click INTERCHANGE Device Config. Utility.
In Windows 3.x, double-click the INTERCHANGE Device
Config. Utility icon in the PanelBuilder Group.
•
Or choose the Workstation Setup command from the File menu of
the PanelBuilder software.
•
The utility also opens at the end of the PanelBuilder installation.
The INTERCHANGE Device Configuration dialog shown on the
next page opens.
INTERCHANGE Device
Configuration Utility
→
PanelBuilder’s File Menu
